Podlite

Podlite is an easy-to-use markup language with a simple, consistent underlying document object model. Podlite can be used for writing language documentation, for documenting programs and modules, as well as for other types of document composition.

The Podlite is a purely descriptive mark-up notation, with no presentational components.

General syntactic structure

Podlite documents are specified using directives, which are used to declare configuration information and to delimit blocks of textual content.

Every directive starts either with an equals sign (=) followed immediately by an identifier.

An identifier composed of an alphabetical character followed by any combination of alphanumeric characters. Alphabetic and numeric definitions encompass relevant Unicode characters. The underscore is consistently treated as alphabetic. Additionally, an identifier can include isolated apostrophes or hyphens, given that the subsequent character is alphabetic.

Directives that start with = can be indented like the code they interleave, but their initial = must still be the first non-whitespace character on their line.

An indented Podlite block is considered to have a virtual left margin, determined by the indentation of its opening delimiter.

In other words, if a directive is indented from the left margin, the column at which the first character of its opening delimiter appears is thereafter considered the first column of the entire block's contents.

The virtual margin treats leading tabs as aligning to tabstops spaced every ($?TABSTOP // 8) characters.

Podlite blocks

The content of a document is specified within one or more blocks. Every Podlite block may be declared in any of three forms: delimited style, paragraph style, or abbreviated style. All of these forms are equivalent.

Anything in a document that is neither a Podlite directive nor contained within a Podlite block is treated as "ambient" material. Typically this would be the source code of the program that the Podlite is documenting. Podlite parsers still parse this text into the internal representation of the file, representing it as a "ambient" block. Renderers will usually ignore such blocks. This is the default mode of the parser.

All directives have a defined terminator and the Podlite parser always reverts to "ambient" at the end of each Podlite directive or block.

The =pod block puts the parser in "pod" mode, treating all text between blocks as implicit paragraph Podlite, even if it's not inside an explicit block.

To keep the parser in "pod" mode, enclose the desired Podlite region in a =pod block:

  =begin pod

  =head1 A heading

  This is Podlite too. Specifically, this is a simple C<para> block

      $this = pod('also');  # Specifically, a code block

  =end pod

The contents of files with the extensions .podlite and .pod6 are implicitly wrapped in a =pod directive.

For .md and .markdown files, the parser operates in "Markdown" mode for the entire file, treating all text as markdown even if it is not inside an =markdown block.

Any other file extension puts the parser in default mode. The =include directive provides a mechanism to override this behavior by using the :mime-type attribute for the included files.

Delimited blocks

Delimited blocks are bounded by =begin and =end markers, both of which are followed by a valid Podlite identifier, which is the typename of the block. Typenames that are entirely lowercase (for example: =begin head1) or entirely uppercase (for example: =begin SYNOPSIS) are reserved.

After the typename, the rest of the =begin marker line is treated as configuration information for the block. This information is used in different ways by different types of blocks, but is always specified using any of:

The first column of the table names the kind of the value. A rule that refers to the kind of a value refers to these names.

All option keys and values are constants: Podlite is a specification language, not a programming language. An option value cannot be a closure.

Whitespace surrounding a value is not significant and is removed. The delimiters that enclose a value determine how it is read.

A single word enclosed in angle brackets is not converted to another type. A comma is retained as part of the value, so :key<a,b> is read as the string a,b. Quotation marks delimit a string and suppress separation by whitespace, which makes :key<'a b'> a string. Guillemets are not quotation marks and are retained as part of the value.

A delimiter with nothing inside it carries the empty value of its kind, so :key<> and :key() are an empty list and :key{} is an empty hash. An empty string is written with quotation marks, as :key('').

Apart from True and False, an unquoted word is not a valid element of a parenthesised list or value of a hash entry. Inside braces an option is read as on the marker line: with no value it denotes the boolean true, and negated it denotes the boolean false. The key of an option is an identifier.

A value that cannot be read is discarded together with its attribute, and parsing of the block continues. Podlite parsers issue a warning that identifies the position of the discarded value.

The configuration section may be extended over subsequent lines by starting those lines with an = in the first (virtual) column followed by a whitespace character. A value in parentheses or braces may continue on such a line. A value in angle brackets or in quotation marks ends with its line.

The lines following the opening delimiter and configuration are the data or contents of the block, which continue until the block's matching =end marker line. For most block types, these contents may be indented if you wish, without them being treated as code blocks. Indented text is only treated as code within =pod, =nested, =item, =code, and semantic blocks.

The general syntax is:

     =begin BLOCK_TYPE  OPTIONAL CONFIG INFO
     =                  OPTIONAL EXTRA CONFIG INFO
     BLOCK CONTENTS
     =end BLOCK_TYPE

For example:

     =begin table  :caption('Table of Contents')
         Constants           1

         Variables           10

         Subroutines         33

         Everything else     57
     =end table

        =begin Name  :required
        =            :width(50)
        The applicant's full name
        =end Name

        =begin Contact  :optional
            The applicant's contact details
        =end Contact

Note that no blank lines are required around the directives; blank lines within the contents are always treated as part of the contents. This is a universal feature of Podlite.

Note also that in the following specifications, a "blank line" is a line that is either empty or that contains only whitespace characters. That is, a blank line matches the following pattern: /^^ \h* $$/. Podlite uses blank lines as delimiters, rather than empty lines, to minimize unpleasant surprises when stray spaces or tabs mysteriously turn up in hitherto empty lines.

Paragraph blocks

Paragraph blocks are introduced by a =for marker and terminated by the next Podlite directive or the first blank line (which is not considered to be part of the block's contents). The =for marker is followed by the name of the block and optional configuration information. The general syntax is:

     =for BLOCK_TYPE  OPTIONAL CONFIG INFO
     =                OPTIONAL EXTRA CONFIG INFO
     BLOCK DATA

For example:

     =for table  :caption('Table of Contents')
         Constants           1
         Variables           10
         Subroutines         33
         Everything else     57

        =for Name  :required
        =          :width(50)
        The applicant's full name

     =for Contact  :optional
        The applicant's contact details

Abbreviated blocks

Abbreviated blocks are introduced by an '=' sign in the first column, which is followed immediately by the typename of the block. The rest of the line is treated as block data, rather than as configuration. The content terminates at the next Podlite directive or the first blank line (which is not part of the block data). The general syntax is:

     =BLOCK_TYPE  BLOCK DATA
     MORE BLOCK DATA

For example:

     =table
         Constants           1
         Variables           10
         Subroutines         33
         Everything else     57

        =Name  The applicant's full name
     =Contact  The applicant's contact details

Note that abbreviated blocks cannot specify configuration information. If configuration is required, use a =for or =begin/=end instead.

Block equivalence

The underlying documentation model treats all block specifications (delimited, paragraph, and abbreviated) the same way. It is possible to choose the form is most convenient for a particular documentation task. In the descriptions that follow, the abbreviated form will generally be used, but should be read as standing for all three forms equally.

For example, although #Headings shows only:

  =head1 Top Level Heading

this automatically implies that you could also write that block as:

  =for head1
  Top Level Heading

or:

  =begin head1
  Top Level Heading
  =end head1

Standard configuration options

Podlite predefines a small number of standard configuration options that can be applied uniformly to any built-in block type. These include:

:caption

This option assigns a title to the given block, which is typically used to create a table of contents.

:id

This option enables the explicit definition of identifiers for blocks and use those IDs for linking purposes (see #Links).

:nested

This option specifies that the block is to be nested within its current context. For example, nesting might be applied to block quotes, to textual examples, or to commentaries. In addition the =code, =item, =input, and =output blocks all have implicit nesting.

Nesting of blocks is usually rendered by adding extra indentation to the block contents, but may also be indicated in other ways: by boxing the contents, by changing the font or size of the nested text, or even by folding the text (so long as a visible placeholder is provided).

Occasionally it is desirable to nest content by more than one level:

    =begin para :nested
    =begin para :nested
    =begin para :nested
    "We're going deep, deep, deep undercover!"
    =end para
    =end para
    =end para

This can be simplified by giving the :nested option a positive integer value:

    =begin para :nested(3)
    "We're going deep, deep, deep undercover!"
    =end para

You can also give the option a value of zero, to defeat any implicit nesting that might normally be applied to a paragraph. For example, to specify a block of code that should appear without its usual nesting:

    =comment Don't nest this code block in the usual way...
    =begin code :nested(0)

                 1         2         3         4         5         6
        123456789012345678901234567890123456789012345678901234567890
        |------|-----------------------|---------------------------|
          line        instruction                comments
         number           code

    =end code

Note that :!nested could also be used for this purpose:

    =Z<>begin code :!nested

:numbered

This option specifies that the block is to be numbered. The most common use of this option is to create numbered headings and ordered lists, but it can be applied to any block.

The numbering conventions for headings and lists are specified in those sections, but it is up to individual renderers to decide how to display any numbering associated with other types of blocks.

Note that numbering is never explicit; it is always implied by context.

:checked

This attribute indicates that a checkbox should be added to that block. It is possible to apply a :checked attributes to any block. The most common use of this option is to create task lists.

For an unchecked checkbox the :!checked is used.

The task list item marker (checkbox) is added to the output. In HTML output, this would be represented as an input type="checkbox" element.

The specification does not define how these checkboxes are interacted with. Implementors are free to choose whether they render them as disabled, unchangeable elements, or handle dynamic interactions like checking and unchecking in the final rendered document.

:folded

This option specifies that the block content is not presented immediately but is available on demand. The attribute controls the initial state: :folded or :folded(1) indicates the content is concealed by default; :!folded or :folded(0) indicates it is revealed by default.

  =for table :folded :caption('Culinary Techniques for Sustainability')
    Sous-vide   Low energy consumption
    ----------  -------------------------
    Steaming    Preserves nutrients
    Baking      Efficient for batch cooking

When applied to a heading block, the attribute governs the heading and all associated lower-level content, forming a hierarchical structure.

  =for head2 :folded
  Green Energy Overview

In non-interactive contexts, the distinction may be expressed through visual means such as sidebar placement or reduced emphasis.

:lang

This option is used to provide information about the programming language used in a specific code block. This helps ensure that the code is displayed and interpreted correctly by rendering engines or syntax highlighters.

Here's a table that lists a few programming languages along with their possible values for the :lang attribute:

Matching languages and lang attribute values

Programming language	Possible :lang values
C++	cpp
CSS	css
HTML	html
Java	java
JavaScript	javascript
Python	python
Raku	raku

If the language is not specified, the default language is used based on the file extension or mime type of the current document.

:allow

This option expects a list of markup codes that are to be recognized within any V<> codes that appear in (or are implicitly applied to) the current block. The option is most often used on =code blocks to allow mark-up within those otherwise verbatim blocks, though it can be used in any block that contains verbatim text. See #Formatting within code blocks.

Selectors

Selectors consist of patterns that help identify and filter specific blocks within documents. Each pattern contains optional source of blocks and block names.

The general syntax is:

EXTERNAL_SOURCE
or
[ EXTERNAL_SOURCE | ] BLOCKS_SELECTOR

...where

• EXTERNAL_SOURCE - optional source of blocks for filtering, default current document,

• BLOCK_SELECTOR - list of patterns; a pattern is a block name or the universal *, optionally followed by a predicate

For example:

Please note that while the Selector blocks provide a way to query and filter specific elements within Markdown files, Markdown itself doesn't have formal named blocks like the Podlite syntax. Instead, Markdown uses a lightweight markup to structure content. The above table provides a mapping between Podlite block names and their corresponding Markdown elements.

The most common use of Selectors is to create table of contents and in the include directive.

Predicates

A pattern may carry a predicate. The predicate is written in square brackets after the block name. It tests the configuration of a block. A block is selected when its name matches the pattern and every condition of the predicate holds.

Conditions are written in the syntax of the block configuration table, so an operator means the same thing in a declaration and in a predicate.

Predicates are case-sensitive. No adjustment to case is provided.

A value containing whitespace is written in quotation marks, as it is in a declaration:

=include file:./guide.podlite | para[ :author('John Doe') ]

Universal pattern

The character * forms a universal pattern, which matches a block of any name and stands in the position of a block name. It is used when the selection is by configuration rather than by name:

=include file:./guide.podlite | *[ :platform<arm> ]

* is not a valid identifier start, so a pattern and a block name cannot be confused.

A universal pattern without a predicate selects every block and filters nothing.

Within a single selection, one attribute may be encountered as several kinds of value, because a universal pattern matches blocks of every name. Every predicate is defined for every kind of value. The selection is not interrupted by a kind it does not expect.

Empty and absent values

An attribute that exists with an empty value is distinct from an attribute that does not exist and from one whose value is false. The following table states the outcome for each predicate:

No predicate distinguishes an empty list from an empty string. An empty list holds no values. An empty string is one value of zero length. Both are false and both satisfy the tests above in the same way. The distinction is preserved in the document tree.

Membership

[ :attr~<V> ] holds when every element of V occurs among the values of the attribute. Values present in the attribute and absent from the operand do not affect the outcome. The condition states what is required to be present. The condition says nothing about what is required to be absent.

The operand of ~<> is read by the rule that governs any value. Whitespace inside the operand separates a list. A single word is a string. Quotation marks produce one element that may contain whitespace.

=for para :id<A> :tags<draft review>
=for para :id<B> :tags<draft review urgent>
=for para :id<C> :tags<draft>
=for para :id<D> :tags<'draft review'>

| para[ :tags~<draft> ]              # A, B, C
| para[ :tags~<draft review> ]       # A, B
| para[ :tags~<'draft review'> ]     # D

An empty operand is an error and is reported when the selector is read. An empty list occurs among any set of values, so the condition would hold for every block and would test nothing.

Membership is not a test for a substring. [ :tags~<spec> ] does not hold for :tags<specification>, and ~<> never falls back to comparing parts of a value.

Addressing the keys of a hash is not defined. Applied to a hash, ~<> yields no match.

Operations in parentheses

The operation is named, and its operands follow the name inside parentheses:

| Invoice[ :author('John Doe') ]             # a value
| Invoice[ :status(in 'draft','issued') ]    # an operation

What follows the opening parenthesis is read as a value when it is one of the forms of the block configuration table. Every other name is the name of an operation. A name standing in that position which this specification does not define is an error, reported when the selector is read.

in is written with one or more operands. An absent operand and an empty operand are both errors, reported when the selector is read.

Literal operands are separated by commas, following the parenthesised list form in the block configuration table. Angle brackets instead separate values with whitespace.

The condition holds when at least one value of the attribute equals an operand. Other values of the attribute do not affect the outcome, as in:

=for note :tags<approved secret>

| note[ :tags(in 'approved') ]      # holds

The operands are numbers or values in quotation marks, separated by commas. Alternatively, a selector supplies the values and is the sole operand. Where the operand is a selector, the condition holds when a value of the attribute is a value the selector yields:

=include file:./guide.podlite | Invoice[ :type(in file:./vocabulary.podlite | defn) ]

From a definition the term is taken, as definition lists state; from a block whose kind defines no single value nothing is taken.

A source is resolved and its content is read before a condition carrying a selector reports a match or a non-match. A source that cannot be resolved is an error, not an empty source. Such a failure establishes neither a match nor a non-match.

Within an operand, a number sign separates an internal address from the path. A path containing that character cannot be written there.

Combining conditions

Whitespace separates one condition from the next. A block is selected only when every condition holds. Whitespace enclosed by brackets, by parentheses or by quotation marks belongs to the condition it appears in.

code[ :lang<python> :numbered ]

A comma separates whole patterns, and a block is selected when it matches any of them:

head1, head2, code[ :lang<python> ]

The result is a set in document order. A block that matches more than one pattern appears once.

Non-matching conditions

A condition naming an attribute that no block declares holds for no block. No diagnostic is required.

A value whose kind does not admit the test is reported as a non-match. The selection is not interrupted, which the universal pattern requires. Under it, values of unexpected kinds are encountered by construction.

Block types

Podlite offers notations for specifying a wide range of standard block types...

Headings

Podlite provides an unlimited number of levels of heading, specified by the =headN block marker. For example:

  =head1 A Top Level Heading

    =head2 A Second Level Heading

      =head3 A third level heading

            =head86 A "Missed it by I<that> much!" heading

While Podlite parsers are required to recognize and distinguish all levels of heading, Podlite renderers are only required to provide distinct renderings of the first four levels of heading (though they may, of course, provide more than that). Headings at levels without distinct renderings would typically be rendered like the lowest distinctly rendered level.

Numbered headings

You can specify that a heading is numbered using the :numbered option. For example:

  =for head1 :numbered
  The Problem

  =for head1 :numbered
  The Solution

      =for head2 :numbered
      Analysis

          =for head3
          Overview

          =for head3
          Details

      =for head2 :numbered
      Design

  =for head1 :numbered
  The Implementation

which would produce:

1. The Problem

2. The Solution

2.1. Analysis

Overview

Details

2.2: Design

3. The Implementation

It is usually better to preset a numbering scheme for each heading level, in a series of configuration blocks:

  =config head1 :numbered
  =config head2 :numbered
  =config head3 :!numbered

  =head1 The Problem
  =head1 The Solution
  =head2   Analysis
  =head3     Overview
  =head3     Details
  =head2   Design
  =head1 The Implementation

Alternatively, as a short-hand, if the first whitespace-delimited word in a heading consists of a single literal # character, the # is removed and the heading is treated as if it had a :numbered option:

  =head1 # The Problem
  =head1 # The Solution
  =head2   # Analysis
  =head3       Overview
  =head3       Details
  =head2   # Design
  =head1 # The Implementation

Note that, even though renderers are not required to distinctly render more than the first four levels of heading, they are required to correctly honour arbitrarily nested numberings. That is:

    =head6 # The Rescue of the Kobayashi Maru

should produce something like:

2.3.8.6.1.9. The Rescue of the Kobayashi Maru

Ordinary paragraph blocks

Ordinary paragraph blocks consist of text that is to be formatted into a document at the current level of nesting, with whitespace squeezed, lines filled, and any special inline mark-up applied.

Ordinary paragraphs consist of one or more consecutive lines of text, each of which starts with a non-whitespace character at (virtual) column 1. The paragraph is terminated by the first blank line or block directive. For example:

  =head1 This is a heading block

  This is an ordinary paragraph.
  Its text  will   be     squeezed     and
  short lines filled. It is terminated by
  the first blank line.

  This is another ordinary paragraph.
  Its     text    will  also be squeezed and
  short lines filled. It is terminated by
  the trailing directive on the next line.
    =head2 This is another heading block

    This is yet another ordinary paragraph,
    at the first virtual column set by the
    previous directive

Within a =pod, =item, =defn, =nested, or semantic block, ordinary paragraphs do not require an explicit marker or delimiters, but there is also an explicit para marker (which may be used anywhere):

  =para
  This is an ordinary paragraph.
  Its text  will   be     squeezed     and
  short lines filled.

and likewise the longer =for and =begin/=end forms. For example:

  =begin para
    This is an ordinary paragraph.
    Its text  will   be     squeezed     and
    short lines filled.

    This is I<still> part of the same paragraph,
    which continues until an...
  =end para

As the previous example implies, when any form of explicit =para block is used, any whitespace at the start of each line is removed during rendering. In addition, within a delimited =begin para/=end para block, any blank lines are preserved.

Code blocks

Code blocks are used to specify pre-formatted text (typically source code), which should be rendered without rejustification, without whitespace-squeezing, and without recognizing any inline markup codes. Code blocks also have an implicit nesting associated with them. Typically these blocks are used to show examples of code, mark-up, or other textual specifications, and are rendered using a fixed-width font.

A code block may be implicitly specified as one or more lines of text, each of which starts with a whitespace character at the block's virtual left margin. The implicit code block is then terminated by a blank line. For example:

  This ordinary paragraph introduces a code block:

    $this = 1 * code('block');
    $which.is_specified(:by<indenting>);

Implicit code blocks may only be used within =pod, =item, =defn, =nested, or semantic blocks.

There is also an explicit =code block (which can be specified within any other block type, not just =pod, =item, etc.):

  The C<loud_update()> subroutine adds feedback:

    =begin code

    sub loud_update ($who, $status) {
        say "$who -> $status";

        silent_update($who, $status);
    }

    =end code

As the previous example demonstrates, within an explicit =code block the code can start at the (virtual) left margin. Furthermore, lines that start with whitespace characters after that margin have subsequent whitespace preserved exactly (in addition to the implicit nesting of the code). Explicit =code blocks may also contain empty lines.

Formatting within code blocks

Although =code blocks automatically disregard all markup codes, occasionally you may still need to specify some formatting within a code block. For example, you may wish to emphasize a particular keyword in an example (using a B<> code). Or you may want to indicate that part of the example is metasyntactic (using the R<> code). Or you might need to insert a non-ASCII character (using the code).

You can specify a list of markup codes that should still be recognized within a code block using the :allow option. The value of the :allow option must be a list of the (single-letter) names of one or more markup codes. Those codes will then remain active inside the code block. For example:

  =begin code :allow<B R>
  sub demo {
      B<say> 'Hello R<name>';
  }
  =end code

would be rendered:

  sub demo {
      say 'Hello name';
  }

Note that the use of the :allow option also makes it possible for verbatim markup codes (such as C<> and V<>) to contain other codes as well.

Assign programming language to code blocks

The :lang attribute will be used to provide information about the programming language used in a particular block of code. This helps in ensuring that the code is correctly rendered and interpreted by the renderers or syntax highlighting tools.

For example:

  =begin code :lang<raku>
  sub demo {
     say 'Hello R<name>';
  }
  =end code

I/O blocks

Podlite also provides blocks for specifying the input and output of programs.

The =input block is used to specify pre-formatted keyboard input, which should be rendered without rejustification or squeezing of whitespace.

The =output block is used to specify pre-formatted terminal or file output which should also be rendered without rejustification or whitespace-squeezing.

Note that, like =code blocks, both =input and =output blocks have an implicit level of nesting. They are also like =code blocks in that they are typically rendered in a fixed-width font, though ideally all three blocks would be rendered in distinct font/weight combinations (for example: regular serifed for code, bold sans-serif for input, and regular sans-serif for output).

Unlike =code blocks, both =input and =output blocks honour any nested markup codes. This is particularly useful since a sample of input will often include prompts (which are, of course, output). Likewise a sample of output may contain the occasional interactive component. Podlite provides special markup codes (K<> and T<>) to indicate embedded input or output, so you can use the block type that indicates the overall purpose of the sample (i.e. is it demonstrating an input operation or an output sequence?) and then use the "contrasting" markup code within the block.

For example, to include a small amount of input in a sample of output you could use the K<> markup code:

  =begin output
      Name:    Baracus, B.A.
      Rank:    Sgt
      Serial:  1PTDF007

      Do you want additional personnel details? K<y>

      Height:  180cm/5'11"
      Weight:  104kg/230lb
      Age:     49

      Print? K<n>
  =end output

Lists

Lists in Podlite are specified as a series of contiguous =item blocks. No special "container" directives or other delimiters are required to enclose the entire list. For example:

  The seven suspects are:

  =item  Happy
  =item  Dopey
  =item  Sleepy
  =item  Bashful
  =item  Sneezy
  =item  Grumpy
  =item  Keyser Soze

List items have one implicit level of nesting:

The seven suspects are:

• Happy

• Dopey

• Sleepy

• Bashful

• Sneezy

• Grumpy

• Keyser Soze

Lists may be multi-level, with items at each level specified using the =item1, =item2, =item3, etc. blocks. Note that =item is just an abbreviation for =item1. For example:

  =item1  Animal
  =item2     Vertebrate
  =item2     Invertebrate

  =item1  Phase
  =item2     Solid
  =item2     Liquid
  =item2     Gas
  =item2     Chocolate

which would be rendered something like:

• Animal

– Vertebrate

– Invertebrate

• Phase

– Solid

– Liquid

– Gas

– Chocolate

Podlite parsers must issue a warning if a "level-N+1" =item block (e.g. an =item2, =item3, etc.) appears anywhere except where there is a preceding "level-N" =item in the same surrounding block. That is, an =item3 should only be specified if an =item2 appears somewhere before it, and that =item2 should itself only appear if there is a preceding =item1.

Note that item blocks within the same list are not physically nested. That is, lower-level items should not be specified inside higher-level items:

    =comment WRONG...
    =begin item1          --------------
    The choices are:                    |
    =item2 Liberty        ==< Level 2   |==<  Level 1
    =item2 Death          ==< Level 2   |
    =item2 Beer           ==< Level 2   |
    =end item1            --------------

    =comment CORRECT...
    =begin item1          ---------------
    The choices are:                     |==< Level 1
    =end item1            ---------------
    =item2 Liberty        ==================< Level 2
    =item2 Death          ==================< Level 2
    =item2 Beer           ==================< Level 2

Ordered lists

An item is part of an ordered list if the item has a :numbered configuration option:

     =for item1 :numbered
     Visito

     =for item2 :numbered
     Veni

     =for item2 :numbered
     Vidi

     =for item2 :numbered
     Vici

This would produce something like:

1. Visito

1.1. Veni

1.2. Vidi

1.3. Vici

although the numbering scheme is entirely at the discretion of the renderer, so it might equally well be rendered:

1. Visito

1a. Veni

1b. Vidi

1c. Vici

or even:

A: Visito

  (i) Veni

 (ii) Vidi

(iii) Vici

Alternatively, if the first word of the item consists of a single # character, the item is treated as having a :numbered option:

     =item1  # Visito
     =item2     # Veni
     =item2     # Vidi
     =item2     # Vici

To specify an unnumbered list item that starts with a literal #, either make the octothorpe verbatim:

    =item V<#> introduces a comment

or explicitly mark the item itself as being unnumbered:

    =for item :!numbered
    # introduces a comment

The numbering of successive =item1 list items increments automatically, but is reset to 1 whenever any other kind of non-ambient Podlite block appears between two =item1 blocks. For example:

    The options are:

    =item1 # Liberty
    =item1 # Death
    =item1 # Beer

    The tools are:

    =item1 # Revolution
    =item1 # Deep-fried peanut butter sandwich
    =item1 # Keg

would produce:

The options are:

1. Liberty

2. Death

3. Beer

The tools are:

1. Revolution

2. Deep-fried peanut butter sandwich

3. Keg

The numbering of nested items (=item2, =item3, etc.) only resets (to 1) when the higher-level item's numbering either resets or increments.

To prevent a numbered =item1 from resetting after a non-item block, you can specify the :continued option:

     =for item1
     # Retreat to remote Himalayan monastery

     =for item1
     # Learn the hidden mysteries of space and time

     I<????>

     =for item1 :continued
     # Prophet!

which produces:

1. Retreat to remote Himalayan monastery

2. Learn the hidden mysteries of space and time

????

3. Prophet!

Task lists

In addition to the ordered list Podlite also supports task lists, which are commonly known as checklists or to-do lists.

To create a task list item just apply a :checked attribute to =item block.

 =for item :checked
 Buy groceries
 =for item :!checked
 Clean the garage

The rendered output looks like this:

[X] Buy groceries
 [ ] Clean the garage

Alternatively, if item content starts with brackets with space ([ ]) the item is treated as having a :!checked attribute. To select a checkbox, add an x in between the brackets ([x]). it eqvivalent of :checked attribute.

For example:

 =item [x] Buy groceries
 =itme [ ] Clean the garage

It possiible to create multilevel to-do lists, which permits the inclusion of various task levels or sub-tasks. Here's an example:

 =item1 [ ] Work
   =item2 [ ] Prepare the presentation
   =item2 [x] Send emails
 =item1 [ ] Home
   =item2 [ ] Vacuum the living room
   =item2 [ ] Water the plants

Unordered lists

List items that are not :numbered or :checked are treated as defining unordered lists. Typically, such lists are rendered with bullets. For example:

    =item1 Reading
    =item2 Writing
    =item3 'Rithmetic

might be rendered:

•  Reading

—  Writing

¤  'Rithmetic

As with numbering styles, the bulletting strategy used for different levels within a nested list is entirely up to the renderer.

Multi-paragraph list items

Use the delimited form of the =item block to specify items that contain multiple paragraphs. For example:

     Let's consider two common proverbs:

     =begin item :numbered
     I<The rain in Spain falls mainly on the plain.>

     This is a common myth and an unconscionable slur on the Spanish
     people, the majority of whom are extremely attractive.
     =end item

     =begin item :numbered
     I<The early bird gets the worm.>

     In deciding whether to become an early riser, it is worth
     considering whether you would actually enjoy annelids
     for breakfast.
     =end item

     As you can see, folk wisdom is often of dubious value.

which produces:

Let's consider two common proverbs:

1. The rain in Spain falls mainly on the plain.

   This is a common myth and an unconscionable slur on the Spanish people, the majority of whom are extremely attractive.

2. The early bird gets the worm.

   In deciding whether to become an early riser, it is worth considering whether you would actually enjoy annelids for breakfast.

As you can see, folk wisdom is often of dubious value.

Definition lists

To create term/definition lists, use a =defn block. This is similar in effect to an =item block, in that a series of =defn blocks implicitly defines a list (but which might then be rendered into HTML using <DL>...</DL> tags, rather than <UL>...</UL> tags)

The first non-blank line of content is treated as a term being defined, and the remaining content is treated as the definition for the term. For example:

    =defn  MAD
    Affected with a high degree of intellectual independence.

    =defn  MEEKNESS
    Uncommon patience in planning a revenge that is worth while.

    =defn
    MORAL
    Conforming to a local and mutable standard of right.
    Having the quality of general expediency.

Like other kinds of list items, definitions can be numbered, using either an option or a leading #:

    =for defn :numbered
    SELFISH
    Devoid of consideration for the selfishness of others.

    =defn # SUCCESS
    The one unpardonable sin against one's fellows.

Nesting blocks

Any block can be nested by specifying a :nested option on it:

    =begin para :nested
        We are all of us in the gutter,E<NL>
        but some of us are looking at the stars!
    =end para

However, qualifying each nested paragraph individually quickly becomes tedious if there are many in a sequence, or if multiple levels of nesting are required:

    =begin para :nested
        We are all of us in the gutter,E<NL>
        but some of us are looking at the stars!
    =end para
    =begin para :nested(2)
            -- Oscar Wilde
    =end para

So Podlite provides a =nested block that marks all its contents as being nested:

    =begin nested
    We are all of us in the gutter,E<NL>
    but some of us are looking at the stars!
        =begin nested
        -- Oscar Wilde
        =end nested
    =end nested

Nesting blocks can contain any other kind of block, including implicit paragraph and code blocks. Note that the relative physical indentation of the blocks plays no role in determining their ultimate nesting. The preceding example could equally have been specified:

    =begin nested
    We are all of us in the gutter,E<NL>
    but some of us are looking at the stars!
    =begin nested
    -- Oscar Wilde
    =end nested
    =end nested

Tables

Simple tables can be specified in Podlite using a =table block. The table may be given an associated description or title using the :caption option.

Columns are separated by two or more consecutive whitespace characters (double-space), or by a vertical line (|) or a border intersection (+), either of which must be separated from any content by at least one whitespace character. Note that only one column separator type is allowed in a single line, but different lines are allowed to use different visible column separator types (that style is not recommended). Using a mixture of visible and non-visible column separator types in a table is an error.

Rows can be specified in one of two ways: either one row per line, with no separators; or multiple lines per row with explicit horizontal separators (whitespace, intersections (+), or horizontal lines: -, =, _) between every row. Either style can also have an explicitly separated header row at the top. If rows are using the two-whitespace-character separator, the row cells should be carefully aligned to ensure the table is interpreted as the user intended.

Each individual table cell is separately formatted, as if it were a nested =para. Note that table rows are expected to have the same number of cells.

This means you can create tables compactly, line-by-line:

    =table
        The Shoveller   Eddie Stevens     King Arthur's singing shovel
        Blue Raja       Geoffrey Smith    Master of cutlery
        Mr Furious      Roy Orson         Ticking time bomb of fury
        The Bowler      Carol Pinnsler    Haunted bowling ball

With header:

 =begin table

    Directive           Specifies
    _________           ____________________________________________________
    C<=begin>           Start of an explicitly terminated block
    C<=config>          Lexical modifications to a block or markup code

 =end table

Or:

 =begin table

    Energy Source                Benefit

    Solar power                  Reduces electricity bills
    Wind energy                  Clean power source
    Hydroelectric power          Highly efficient
    Geothermal energy            Low emissions
    Biomass                      Reduces waste

=end table

or line-by-line with multi-line headers:

    =table
        Superhero     | Secret          |
                      | Identity        | Superpower
        ==============|=================|================================
        The Shoveller | Eddie Stevens   | King Arthur's singing shovel
        Blue Raja     | Geoffrey Smith  | Master of cutlery
        Mr Furious    | Roy Orson       | Ticking time bomb of fury
        The Bowler    | Carol Pinnsler  | Haunted bowling ball

or with multi-line headers and multi-line data:

    =begin table :caption('The Other Guys')

                        Secret
        Superhero       Identity          Superpower
        =============   ===============   ===================
        The Shoveller   Eddie Stevens     King Arthur's
                                          singing shovel

        Blue Raja       Geoffrey Smith    Master of cutlery

        Mr Furious      Roy Orson         Ticking time bomb
                                          of fury

        The Bowler      Carol Pinnsler    Haunted bowling ball

    =end table

Advanced Table Format

Tables may be constructed using =row and =cell blocks. The =row blocks represent individual rows within the table.

The =cell blocks exist within rows and contain the actual content of the table. These cells can contain text, data, or other blocks.

  =begin table

  =begin row
    =cell Fruits
    =cell Bananas
    =cell Yellow and ripe
  =end row

  =begin row
    =cell Vegetables
    =cell Carrots
    =begin cell
     =para Crunchy and orange
    =end cell
  =end row

  =end table

Each =row block may have an optional :header attribute, designating it as a header row. Header rows typically contain labels or titles for columns and are visually distinct.

  =begin table

  =begin row :header
    =cell Category
    =cell Product
    =cell Description
  =end row

  =begin row
    =cell Fruits
    =cell Bananas
    =cell Yellow and ripe
  =end row

  =begin row
    =cell Vegetables
    =cell Carrots
    =cell Crunchy and orange
  =end row

  =end table

The =cell blocks can also have two important attributes:

:colspan

This attribute specifies the number of columns a cell should span horizontally. It allows cells to merge and occupy multiple adjacent columns, creating a visually unified cell.

:rowspan

This attribute determines how many rows a cell should span vertically. Cells with :rowspan can cover multiple rows in a table, creating a vertical merge effect.

The following examples demonstrate how :colspan and :rowspan attributes are used to create tables with merged cells, which is particularly useful for complex data structures.

    =begin table

    =begin row :header
      =for cell :colspan(2)
      Item and Quantity
      =cell Description
    =end row

    =begin row
      =cell Apples
      =cell 5
      =for cell :rowspan(2)
      Fruit for snacking
    =end row

    =begin row
      =cell Bananas
      =cell 3
    =end row

    =end table

The resulting table is rendered as follows:

---------------------------------------------------------------
    |         Item and Quantity        |     Description          |
    |----------------------------------|--------------------------|
    |   Apples     |      5            |                          |
    |--------------|-------------------|    Fruit for snacking    |
    |   Bananas    |      3            |                          |
    ---------------------------------------------------------------

Each =row block may only contain =cell blocks or blank lines as delimiters. All other types of blocks within the =row are implicitly wrapped by =cell blocks.

For example:

 =begin table

  =begin row :header
    =cell Diagram or Picture
    =cell Description
  =end row

  =begin row
    =picture spacecraft_in_orbit.jpg
    =para
    A vehicle designed for space travel
  =end row

  =begin row
   =Mermaid
       graph TD;
       A[Space Station] --> B[Mars Base]

   A space station connected to a Mars base
  =end row

 =end table

Cell spanning attributes and nested block content within cells are semantic properties of the table document model and are preserved in the document tree.

For loading external CSV or TSV data into tables, use =data-table (#Data-table blocks).

Error Recovery

The column separator type is determined per line. If visible separators (| or +) are present, they are used; otherwise, sequences of two or more consecutive whitespace characters serve as separators. Mixed separator types across lines produce a warning; the table is not rejected.

The expected cell count is established from the header row or, in its absence, the row with the most cells. Rows with fewer cells are padded with empty cells; rows with excess cells are truncated. In both cases, a warning is issued.

For =row/=cell tables, separator recovery does not apply, but mismatched cell counts produce a warning.

For tables sourced from file: or data: references, three levels of error are defined. If the source cannot be resolved, an error is issued and the table is rendered as an empty block. If the source cannot be interpreted as CSV, the content is rendered as a =code block. If the CSV contains rows with unequal field counts, parsing proceeds with padding for missing fields, and a warning is issued.

Named or modular custom blocks

Blocks whose names contain at least one uppercase and one lowercase letter are assumed to be destined for specialized renderers or parser plug-ins. For example:

    =begin Xhtml
    <object type="video/quicktime" data="onion.mov">
    =end Xhtml

or:

  =Image http://www.perlfoundation.org/images/perl_logo_32x104.png

Ideally, each named block should have a corresponding handler responsible for its rendering and processing.

In the absence of a handler for named block, the implementation should allow the content to degrade gracefully, ensuring that the core message or functionality remains accessible even if some advanced features cannot be rendered. As result, that blocks my be displayed as verbatim or placeholder content or even not rendered at all.

Alongside the verbatim or placeholder content, the renderer could provide an unobtrusive yet informative error message, explaining that the named block could not be processed.

Note that all block names consisting entirely of lowercase or entirely of uppercase letters are reserved. See #Semantic blocks.

To check custom markup codes, refer to #Custom markup codes.

Data-table blocks

The =data-table block renders CSV and TSV tables. It accepts data in three forms: inline body, an external file via :src, or a referenced =data block. :columns declares column projection; :rename declares display name overrides.

The inline body form embeds the source data:

  =begin data-table :mime-type('text/csv; header=present')
    name,age,city
    Alice,30,London
    Bob,25,Paris
  =end data-table

The external file form references a CSV or TSV file via the :src option, as in:

  =for data-table :src<file:./planets.csv>
  =    :columns<name radius_km>
  =    :caption('Inner planets')

The reference form refers to a named =data block:

  =begin data :key<sales> :mime-type('text/csv; header=present')
    quarter,region,revenue
    Q1,EU,120
  =end data

  =for data-table :src<data:sales> :columns<quarter revenue>

The body is verbatim and is parsed per :mime-type using RFC 4180 for text/csv or RFC 4180 §3 for text/tab-separated-values.

The standard :allow option enables markup codes within each cell; listed codes are interpreted after the cell is parsed from CSV or TSV. Without :allow, cell content is plain text.

The :mime-type option declares the format. With :src<data:X>, :mime-type is inherited from the referenced block; declaring it on =data-table in this case produces an error. With :src<file:X.ext>, :mime-type may be omitted and is inferred from the file extension. With :src<http:> or :src<https:>, :mime-type may be omitted and is inferred from the HTTP Content-Type response header. For inline body, :mime-type is required.

Error recovery follows =table rules (#Error Recovery).

Each =data-table block can include the following attributes:

:src

This option declares the source URI. Accepted schemes are file: for local files, data: for references to =data blocks by key, http: and https: for remote resources, and doc: for cross-document references. When the scheme is omitted, file: is the default. For example:

  :src<file:./planets.csv>
  :src<data:sales>
  :src<https://example.com/data.csv>

Relative paths in file: URIs resolve against the file declaring the directive, not the parent including document.

The :src option and inline body content are mutually exclusive; declaring both produces an error at parse time.

:columns

This option declares ordered column projection: which source columns appear in the output and in what order. Numeric indices refer to column position (1-based) in the source, not row position. For example:

  :columns<product revenue>
  :columns(1,3,5)
  :columns<revenue product>

Output order matches list order; columns absent from the list are excluded. Omitting the option renders all source columns in their source order.

An empty value for :columns produces an error; omit the option to render all columns. Out-of-range indices produce an error.

:rename

This option declares display name overrides for projected columns. The value is a hash mapping source identifiers, either names or indices, to display strings. For example:

  :rename{revenue=>'USD'}
  :rename{1=>'Time', 2=>'Action'}
  :rename{product=>'Product name'}

Only columns appearing as hash keys receive overrides; other columns retain their source name when header=present or numeric index when header=absent.

Hash keys referring to columns absent from :columns (or from the source when :columns is omitted) produce an error.

Podlite comments

Podlite comments refers to Podlite blocks that should not be displayed by any renderer. However, they are still may be part of the internal Podlite representation.

Comments are useful for meta-documentation (documenting the documentation):

    =comment Add more here about the algorithm

and for temporarily removing parts of a document:

  =item # Retreat to remote Himalayan monastery

  =item # Learn the hidden mysteries of space and time

  =item # Achieve enlightenment

  =begin comment
  =item # Prophet!
  =end comment

Data blocks

The =data block is used to embed various types of data directly into a document.

For example, to include a CSV file in a document, it is possible to use the following syntax:

  =begin data :key<sales_data> :mime-type<text/csv>
    name,month,amount
    John Doe,January,1000
    Jane Doe,February,1500
  =end data

Each =data block can be given a :key option, to name it. The contents of any =data block with a key are addressable via the data: schema. For example:

  =begin data :key<employee_data> :mime-type<text/csv>
    id,name,position,department
    1,John Doe,Manager,Marketing
    2,Jane Smith,Developer,Engineering
    3,Bob Brown,Designer,Product
  =end data

  =table data:employee_data

Each =data block can include several attributes to provide additional information about the contained data:

:filename

This option specifies the original file name of the embedded data, which can be used to hint at the type of data contained if the :mime-type is not explicitly provided.

:mime-type

This option indicates the MIME type of the data, such as image/png for PNG images, which helps determine how the data should be interpreted and processed.

The header MIME parameter (per RFC 4180 §3) is recognised on :mime-type for CSV and TSV content. It accepts present or absent, with default absent. When header=present, the renderer treats the first row as column labels in =table data:X:

  =begin data :key<planets> :mime-type('text/csv; header=present')
    name,radius_km,moons
    Mercury,2440,0
    Venus,6052,0
    Earth,6371,1
    Mars,3390,2
  =end data

  =for table :caption('Inner planets')
  data:planets

For =data-table blocks, the :mime-type option may be omitted when the format can be inferred from the source. With :src<file:X.ext>, the format is inferred from the file extension via the MIME extension table below; matching is case-insensitive and multi-dot filenames use the last extension component. With :src<http:> or :src<https:>, the format is inferred from the HTTP Content-Type response header. With :src<data:X>, the MIME type is inherited from the referenced =data block.

For inline body and for sources where inference fails (unknown file extension, missing or generic HTTP Content-Type, absent file extension), :mime-type is required and its omission produces an error. An explicit :mime-type always overrides inference.

Here is a list of common MIME types and their corresponding file extensions:

MIME Type	File Extension
text/plain	.txt
text/markdown	.md, .markdown
text/podlite	.podlite, .pod6
application/json	.json
application/xml	.xml
image/jpeg	.jpg, .jpeg
image/png	.png
application/pdf	.pdf
application/zip	.zip
audio/mpeg	.mp3
video/mp4	.mp4
application/msword	.doc, .docx
text/csv	.csv
text/tab-separated-values	.tsv, .tab

:access-time and :modify-time

These attributes record the times when the data was last accessed or edited.

:encoding

This option specifies the encoding method used to store the data. For non-text data, such as images in PNG format, the encoding method base64 is used.

Example of storing images in =data blocks:

  =begin data :key<Logo> :filename<Logo.png> :mime-type<image/png>
  = :access-time<2022-01-01T00:00:00Z>  :modify-time<2022-01-02T10:00:00Z>
  = :encoding<base64>
  iVBORw0KGgoAAAANSUhEUgAAAAMAAAAFCAYAAACAcVaiAAAAS0lEQVR4AWPOPfjpvWZSW4db
  ZLk+kwTHP24HUQYGfi4WTiZVAcYfDtIMDCJc/38xK6TWth37wcrw7cufF8yeeWUGrL8Z33Ey
  /t0HAMBnF2nt5sNRAAAAAElFTkSuQmCC
  =end data

  =picture data:Logo

In the example above, we have a =data block with :key Logo that stores the base64-encoded image data. We also specify the filename, mime type, access time, and edit time as attributes of the =data block.

The image can then be referenced using the =picture block with the scheme data: and the block name Logo.

The =data blocks are just regular Podlite blocks and may appear anywhere within a source file, and as many times as required.

Note that in Podlite, it is possible to specify =data blocks after the point in the source where their contents will be used.

=data blocks are never rendered by the standard Podlite renderers.

Semantic blocks

All uppercase block typenames are reserved for specifying standard documentation, publishing, or source components.

Standard semantic blocks include:

    =NAME
    =AUTHOR
    =VERSION
    =SYNOPSIS
    =DESCRIPTION
    =USAGE
    =INTERFACE
    =METHOD
    =SUBROUTINE
    =OPTION
    =DIAGNOSTIC
    =ERROR
    =WARNING
    =DEPENDENCY
    =BUG
    =SEE-ALSO
    =ACKNOWLEDGEMENT
    =COPYRIGHT
    =DISCLAIMER
    =LICENCE
    =LICENSE
    =TITLE
    =SECTION
    =CHAPTER
    =APPENDIX
    =TOC
    =INDEX
    =FOREWORD
    =SUMMARY

The plural forms of each of these keywords are also reserved, and are aliases for the singular forms.

Most of these blocks are typically used in their full delimited forms:

    =begin SYNOPSIS
        use Magic::Parser;

        my Magic::Parser $parser .= new();

        my $tree = $parser.parse($fh);
    =end SYNOPSIS

Semantic blocks can be considered to be variants of the =head1 block in most respects (and most renderers will treat them as such). The main difference is that, in a =head1 block, the heading is the contents of the block; whereas, in a semantic block, the heading is derived from the typename of the block itself and the block contents are instead treated as the =para or =code block(s) belonging to the heading.

The use of these special blocks is not required; you can still just write:

    =head1 SYNOPSIS
    =begin code :lang<raku>
        use Magic::Parser

        my Magic::Parser $parser .= new();

        my $tree = $parser.parse($fh);
    =end code

However, using the keywords adds semantic information to the documentation, which may assist various renderers, summarizers, coverage tools, document refactorers, and other utilities. This is because a semantic block encloses the text it controls (unlike a =head1, which merely precedes its corresponding text), so using semantic blocks produces a more explicitly structured document.

Note that there is no requirement that semantic blocks be rendered in a particular way (or at all). Specifically, it is not necessary to preserve the capitalization of the keyword. For example, the =SYNOPSIS block of the preceding example might be rendered like so:

3.  Synopsis

    use Raku::Magic::Parser;

    my $rep = Raku::Magic::Parser.parse($fh, :all_pod);

Table of contents

The =toc block creates an autogenerated table of contents (TOC) in a document. The TOC is an index of section titles within the document, and its structure is determined by the document's organization.

The first non-blank line of =toc content is treated as a selector.

For example:

 =toc head1, head2, head3, item1, item2, table

or:

  =toc  head1, head2, head3

The TOC displays without a caption by default. However, a caption can be specified using the :caption attribute of the =toc block.

For example:

  =for toc :caption('Table of contents')
  head1, head2, head3

The TOC entries are built using the :caption attribute content within the block. If this attribute is not present, the text presentation of the block's content serves as the TOC entry.

The depth of the generated TOC is determined by the "Selector" argument. The selector is processed, and headers or filtered blocks that allow levels are used to build the TOC levels. If a block lacks an associated level, it is rendered at a level one higher than the previous block with a level in the TOC.

Note that all semantic blocks are treated as equivalent to head1 headings, and the =item1/=item equivalence is preserved.

The :folded-levels attribute indicates which levels of the TOC should be folded.

 =for toc :folded-levels(2,3) :caption('Table of contents')
    head1, head2, item1

If the :folded-levels attribute is provided with a set of key-value pairs, it indicates the folding state of each specified level.

For example:

  =for toc  :folded-levels{ 2=>1, 4 => 1, 3=>0 }
    head1, head2, head3, item1, item2

The value 0 for level 3 indicates that this level should remain unfolded. Levels 2 and 4 are folded.

This configuration enables customized folding within the TOC.

The TOC is inserted at the location of the =toc block.

To enable the autogenerated TOC controlled by the renderer, set the :toc document attribute for the =pod block. In this case, the specific configuration and outcome of the TOC are determined by the renderer implementation.

Include directive

The =include directive enables reuse of specific parts of documents within project sources. It is useful for complex documents that combine sections from different files while maintaining overall context and structure.

The =include construct is classified as a directive, consistent with =config and =alias. As a directive, =include references external content rather than containing it directly.

The =include directive is followed by a "Selector" that specifies the content to be included.

In this example, the content of the file chapter01.pod6 located in the ./includes directory is included:

=include file:./includes/chapter01.pod6

A wildcard "Selector" enables inclusion of content from all the Markdown files:

  =include file:./includes/*.md

It is possible to include blocks from the same document. This feature proves valuable when reusing parts of existing content.

For instance, a semantic block =VERSION can be included as demonstrated:

=include VERSION
=VERSION 1.0.0

or, equivalently:

=VERSION 1.0.0
=VERSION 1.0.0

Podlite detects the type of the included file by its extension. For example, if the included file has a .md extension, it is treated as a Markdown file.

To override the type of the included file, the :mime-type attribute is placed on the directive line after the source URI. For example:

=include file:./includes/text.txt :mime-type('text/podlite')

The :mime-type attribute lets the parser handle files whose extension does not match their actual type.

External content can introduce vulnerabilities such as code injection. Tools displaying included content should provide warnings.

=set directives accumulated before =include apply to the first block of the resolved included content (resolution-time targeting). The =include directive itself does not receive =set attributes. Full discipline: Block attribute assignment with =set.

Section boundaries

The =boundary directive marks a structural transition between major document sections such as chapters, parts, or topics. The transition is semantic, not presentational.

A =boundary is a directive, not a block. Hence, there is no paragraph or delimited form of the =boundary directive. It accepts an optional :caption attribute that describes the transition:

=boundary

=boundary :caption<BOUNDARY_DESCRIPTION>

Boundaries are placed between blocks, not within them, at the same structural level as the blocks they separate:

=head1 Chapter One
Content of chapter one.

=boundary

=head1 Chapter Two
Content of chapter two.

Rendering is format-specific. Renderers may use page breaks (paginated output), thematic breaks (web), or separator lines (plain text), and may ignore the directive when boundaries are not supported. The :caption attribute is descriptive metadata; renderers may surface it as a header, navigation entry, or omit it.

Test blocks

=test

A block stating a piece of source and one or more statements that must hold of what a parser makes of it.

The statements are written with selectors. A test contains one or more =assert blocks. It may contain =fixture blocks, each a document an assertion of it may be resolved against under the rule stated below. It may contain =resource blocks where the subject of the test is the resolution of a path:

  =begin test :id<heading-carries-its-level>

  =begin fixture
  =head2 Overview
  =end fixture

  =for assert :caption('a second-level heading is recognised as such')
  head2

  =end test

A test containing no =assert does not pass. An implementation that does not recognise a child of =test reports the test as skipped rather than failed; one it recognises but cannot satisfy is a failure.

The blocks a test contains

=fixture

A verbatim block whose body is a document in its own right, carried as Podlite source.

The body of a =fixture is not processed by the document that holds it: nothing in it is read as that document's markup and nothing in it is resolved. It is still passed to the parser verbatim where an assertion is resolved against the fixture. Anything a test requires besides the body is declared as =resource and is not written into the body.

A test may contain more than one =fixture. Only another =fixture ends the reach of one, and whatever else stands between, child of the test or not, leaves it unchanged.

=assert

A verbatim block carrying a selector expression.

An assertion holds according to whether it carries :absent:

• Without :absent, the assertion holds when the selector matches at least one block, and fails when it matches none.

• With :absent, the assertion holds when the selector matches no block, and fails when it matches one or more.

Where a test contains several =assert blocks, it passes when every assertion holds. Their order among themselves carries no meaning; position relative to a =fixture decides which document an assertion takes.

An assertion states that something is present somewhere in the document, not that it holds for every block. A statement of that kind is written with :absent over the opposite condition. That every invoice carries the attribute :number is stated by requiring that none lacks it:

  =for assert :absent
  Invoice[ :!?number ]

=resource

A verbatim block carrying content the test requires to be reachable by a path.

Two properties are fixed of a declared resource:

• The name is reachable only while the body of a =fixture of the same test is read. A reference in that body, or inside a resource reached from it, obtains only what the test declares.

• How the content is made reachable is not fixed here, and an implementation that cannot write to a filesystem is not excluded.

A resource is reached from the body of a fixture by the path it declares:

  =begin test :id<include-reaches-resource>

  =begin resource :name<includes/guide.podlite>
  =head1 Guide
  =end resource

  =begin fixture
  =include file:./includes/guide.podlite
  =end fixture

  =for assert
  head1

  =end test

A declared name is given relative to the body of the =fixture an assertion is resolved against. A directive or markup code in that body resolves its relative paths against the file declaring it, and not against the parent including document.

Options

:id and :caption are the standard options of those names. :id names a test; :caption records what a test, or a single assertion, is for.

  =begin test :id<value-comma-stays> :caption('a comma inside a value stays part of it')

  =begin fixture
  =for para :one<a,b>
  text
  =end fixture

  =for assert :caption('the value is one string')
  para[ :one<a,b> ]

  =end test

:name

The path under which the content of a =resource is made reachable. Its form is the form of the reference that resolves it.

:absent

Written on an =assert, gives the assertion its negative sense.

The document an assertion is resolved against

An assertion that names a source is resolved against that source. An assertion that names none is resolved against the document the implementation has made current.

Which document that is follows three cases in order:

• a document supplied to the implementation from outside;

• where none is supplied, the body of the =fixture nearest preceding the assertion;

• where neither is present, the document in which the test sits.

Where a document is supplied from outside, the bodies of =fixture are not read as the input of the test. That a supplied document happens to be the one containing the test does not change this.

The file the tests are taken from is not a supplied document. A document is supplied only where the implementation is told to examine it, separately from being told where to find the tests.

A failure against a =fixture is about the implementation: the text is fixed and its reading is not. A failure against a supplied document is about the document.

A relative path in the source of an assertion is resolved against the file the test is written in, and not among the declared resources of the test.

An assertion whose named source cannot be obtained does not hold, whether or not it carries :absent. A missing source is not a document in which nothing matched.

A document containing tests

Where the document an assertion is resolved against is the one containing the test, the =test blocks of that document are part of it and a selector reaches them: an assertion written over every block of a document matches the tests written in it.

Walking a document does not run the tests found in it. An implementation resolves the assertions of the test it was given, and a =test block met while walking is not a test to obtain.

Inserting pictures

Podlite allows to include images using a =picture block with an inline version represented as P<alternative text|source of the image>:

 =picture astronaut.png
 =para In the vast expanse of the cosmos, an intrepid P<astronaut|astronaut.png>
 floats weightlessly above the Earth.

The first non-blank line of content within the =picture block specifies the source of the image, and the remaining content is treated as caption.

This source can be either local or remote, and it can be specified using different schemas: https: for remote images, file: for local ones, or data: for embedded images in the document. If no schema is provided, file: is used as default.

 =picture https://example.com/image.jpg
 =picture file:/local/image.png
 =picture /local/image.png
 =picture ../image.png
 =picture data:Logo

Following the source line, it possible to include an image caption.

 =picture astronaut.png
 In the vast expanse of the cosmos, an intrepid B<astronaut>
 floats weightlessly above the Earth.

In the delimited form of =picture, multiple text blocks can be included:

 =begin picture

 In the vast expanse of the cosmos, an intrepid B<astronaut>
 floats weightlessly above the Earth.

 This astronaut explores the vastness of space.

 =end picture

All inline markup codes supported by ordinary paragraph blocks can be used within picture captions.

A caption can also be defined using the :caption attribute:

 =for picture :caption<diagram>

Mathematical formulas

To include mathematical formulas, use a =formula block with an inline version represented as F<>.

To insert mathematical expressions, use LaTeX-style syntax, which is a commonly used format for writing mathematical equations.

  =formula
  x = \frac{-b \pm \sqrt{b^2 - 4ac}}{2a}

  In a right triangle, the length of the hypotenuse can be calculated
  using the Pythagorean theorem: F<a^2 + b^2 = c^2>.

  Euler's identity, F<e^{i\pi} + 1 = 0>, is a fundamental equation in
  complex analysis.

The formula caption can be defined using the :caption attribute:

  =for formula  :caption('Quadratic Formula')
  x = \frac{-b \pm \sqrt{b^2 - 4ac}}{2a}

Markdown support

Podlite includes built-in support for Markdown, making it easy to include Markdown content within Podlite documents. This is achieved using the =markdown block.

  =begin markdown

  ## Markdown Example

  You can use all the standard Markdown syntax within this block. For example:

  - *Italic text* using asterisks or underscores: *italic* or _italic_.
  - **Bold text** using double asterisks or underscores: **bold** or __bold__.
  - [Links](https://example.com) with the `[text](url)` syntax.
  - Unordered lists using `-`, `*`, or `+`:

  - Item 1
  - Item 2

  - Ordered lists using numbers:

  1. First item
  2. Second item

  - Code blocks with backticks:

  ```python
  def hello_world():
      print("Hello, World!")
  ```

  - Blockquotes with the `>` symbol:

    > This is a blockquote.

  =end markdown

This block allows to seamlessly combine Podlite's structured blocks with the flexibility of Markdown.

Fenced code block attributes

Within markdown content, fenced code blocks may include Podlite configuration attributes following the language identifier. The language identifier on the opening fence line maps directly to the :lang attribute of the native =code block.

  ```python
  def hello():
      print("Hello")
  ```

This fenced code block is semantically equivalent to:

  =begin code :lang<python>
  def hello():
      print("Hello")
  =end code

Both backtick (```) and tilde (~~~) fence delimiters are supported. The two forms are semantically identical.

Extended attributes may be specified after the language identifier using standard Podlite configuration syntax:

  ```python :line-numbers :highlight<2,5-7> :caption<Example>
  def fibonacci(n):
      if n <= 1:
          return n
      return fibonacci(n-1) + fibonacci(n-2)
  ```

This is equivalent to:

  =begin code :lang<python> :line-numbers :highlight<2,5-7> :caption<Example>
  def fibonacci(n):
      if n <= 1:
          return n
      return fibonacci(n-1) + fibonacci(n-2)
  =end code

All attributes defined for =code blocks in this specification are available on fenced code blocks. The complete attribute syntax is described in the block configuration table.

Implementation of extended attributes beyond the language identifier is optional. Parsers not supporting extended attributes parse the language identifier and either ignore trailing content or emit a warning, continuing processing in accordance with the graceful degradation principle.

Common attribute patterns found in various markdown implementations may be mapped to Podlite notation as follows:

Markup codes

Markup codes enable inline markup within the text of (most) Podlite block types. They are a form of block that can contain only other markup codes. Specifically, markup codes can nest:

    B<I shall say this loudly
    Z<and repeatedly>
    and with emphasis.>

All Podlite markup codes consist of a single capital letter followed immediately by a set of angle brackets. The brackets contain the text or data to which the markup code applies. A set of single angles (<...>), a set of double angles («...»), or multiple single-angles (<<<...>>>) can be used.

Within angle delimiters, you cannot use sequences of the same angle characters that are longer than the delimiters:

    =comment
        These are errors...

    C< $foo<<bar>> >
    The Perl 5 heredoc syntax was: C< <<END_MARKER >

Sequences of angles that are the same length as the delimiters can be used, but they must be balanced. For example:

C<  $foo<bar>   >
    C<< $foo<<bar>> >>

If an unbalanced angle is needed, either use different delimiters:

    C«$foo < $bar»
    The Perl 5 heredoc syntax was: C« <<END_MARKER »

or delimiters with more consecutive angles than the text contains:

    C<<$foo < $bar>>
    The Perl 5 heredoc syntax was: C<<< <<END_MARKER >>>

A markup code ends at the matching closing angle bracket(s), or at the end of the enclosing block or markup code in which the opening angle bracket was specified, whichever comes first (this includes paragraph and abbreviated blocks, ending with blank a line). Podlite parsers are required to issue a warning whenever a markup code is terminated by the end of an outer block rather than by its own delimiter (unless the user explicitly disables the warning).

Significance indicators

Podlite provides three markup codes that flag their contents with increasing levels of significance:

• The U<> markup code specifies that the contained text is unusual or distinctive; that it is of minor significance. Typically such content would be rendered in an underlined style.

• The I<> markup code specifies that the contained text is important; that it is of major significance. Such content would typically be rendered in italics or in <em>...</em> tags

• The B<> markup code specifies that the contained text is the basis or focus of the surrounding text; that it is of fundamental significance. Such content would typically be rendered in a bold style or in <strong>...</strong> tags.

Mistake marking

The code O<> can be used for strikethrough text, where 'O' stands for "Overstrike." This indicates that certain words are a mistake and should not be included in the document.

O<The sky is green.> Our planet's sky is usually blue.

Text positioning

Podlite provides two markup codes for positioning characters or words.

• To create subscript text, use the J<> markup code, where 'J' represents "Junior text." Subscript positions one or more characters slightly below the normal line of type.

  H2O


  This code renders as H<sub>2</sub>O, which signifies that the '2' is positioned slightly below the baseline, as is often seen in chemical formulas like H₂O (water).

• To create superscript text, it possible to use the H<> markup code, where 'H' stands for "High text." Superscript positions one or more characters slightly above the normal line of type

  X2


  This code renders as X<sup>2</sup>, indicating that the '2' is positioned slightly above the baseline. This is commonly used for mathematical exponents, as in X².

Definitions

The D<> markup code indicates that the contained text is a definition, introducing a term that the adjacent text elucidates. It is the inline equivalent of a =defn block. For example:

    There ensued a terrible moment of D<coyotus interruptus>: a brief
    suspension of the effects of gravity, accompanied by a sudden
    to-the-camera realization of imminent downwards acceleration.

A definition may be given synonyms, which are specified after a vertical bar and separated by semicolons:

    A D<markup code|markup codes;formatters> provides a way
    to add inline mark-up to a piece of text.

A definition would typically be rendered in italics or <dfn>...</dfn> tags and will often be used as a link target for subsequent instances of the term (or any of its specified synonyms) within a hypertext.

Example specifiers

Podlite provides markup codes for specifying inline examples of input, output, code, and metasyntax:

• The T<> markup code specifies that the contained text is terminal output; that is: something that a program might print out. Such content would typically be rendered in a fixed-width font or with <samp>...</samp> tags. The contents of a T<> code are always space-preserved (as if they had an implicit S<...> around them). The T<> code is the inline equivalent of the =output block.

• The K<> markup code specifies that the contained text is keyboard input; that is: something that a user might type in. Such content would typically be rendered in a fixed-width font (preferably a different font from that used for the T<> markup code) or with <kbd>...</kbd> tags. The contents of a K<> code are always space-preserved. The K<> code is the inline equivalent of the =input block.

• The C<> markup code specifies that the contained text is code; that is, something that might appear in a program or specification. Such content would typically be rendered in a fixed-width font (preferably a different font from that used for the T<> or K<> markup codes) or with <code>...</code> tags. The contents of a C<> code are space-preserved and verbatim. The C<> code is the inline equivalent of the =code block.

  To include other markup codes in a C<> code, the code can be lexically reconfigured:

    =begin para
    =config C< :allow<E I>>
    Raku makes extensive use of the C<E<laquo>> and C<E<raquo>>
    characters, for example, in a hash look-up:
    C<%hashI<E<laquo>>keyI<E<raquo>>>
    =end para


  To enable entities in every C<...>, place a =config C<> :allow<E> at the top of the document.

• The R<> markup code specifies that the contained text is a replaceable item, placeholder, or metasyntactic variable. It is used to indicate a component of a syntax or specification that should eventually be replaced by an actual value. For example:

    The basic C<ln> command is: C<ln> R<source_file> R<target_file>


  or:

    Then enter your details at the prompt:
    =for input
        Name: R<your surname>
          ID: R<your employee number>
        Pass: R<your 36-letter password>


  Typically replaceables would be rendered in fixed-width italics or with <var>...</var> tags. The font used should be the same as that used for the C<> code, unless the R<> is inside a K<> or T<> code (or the equivalent =input or =output blocks), in which case their respective fonts should be used.

Verbatim text

The V<> markup code treats its entire contents as being verbatim, disregarding every apparent markup code within it. For example:

The B<V< V<> >> markup code disarms other codes
    such as V< I<>, C<>, B<>, and M<> >.

Note that the V<> code only changes the way its contents are parsed, not the way they are rendered. That is, the contents are still wrapped and formatted like plain text, and the effects of any markup codes surrounding the V<> code are still applied to its contents. For example, the previous example is rendered:

The V<> markup code disarms other codes such as I<>, C<>, B<>, and M< >.

You can prespecify markup codes that remain active within a V<> code, using the :allow option.

Inline comments

The Z<> markup code indicates that its contents constitute a zero-width comment, which should not be rendered by any renderer. For example:

  The "exeunt" command Z<Think about renaming this command?> is used
  to quit all applications.

In certain scenarios, the Z<> code is used to break up text that would otherwise be considered mark-up:

  In certain scenarios, the ZZ<><> code is used to break up text that
  would otherwise be considered mark-up.

That technique still works, but it's now easier to accomplish the same goal using a verbatim markup code:

  In certain scenarios, the V<V<Z<>>> code is used to break up text that
  would otherwise be considered mark-up.

Moreover, the C<> code automatically treats its contents as being verbatim, which often eliminates the need for the V<> as well:

  In certain scenarios, the V<C<Z<>>> code was widely used to break up text
  that would otherwise be considered mark-up.

The Z<> markup code is the inline equivalent of a =comment block.

Content masking

The G<> markup code marks an inline text fragment, and the :masked attribute marks an entire block, as guarded. The original content is preserved in the document model; only the rendered output is concealed.

The mechanism provides presentation-layer concealment for sensitive content (API tokens, credentials, personally identifiable information, age-restricted material). It complements other security layers such as source file access controls and authenticated build pipelines.

The password is G<hunter2> and must not be exposed.

=for BLOCKTYPE :masked

The mask character is determined by the renderer; the recommended default is U+2588 (█ FULL BLOCK). Whitespace structure is preserved in the masked output.

Two render modes are defined:

• Production mode (default): guarded content is concealed

• Draft mode: guarded content is rendered visibly for editing and review

Selection between modes is implementation-defined (renderer-controlled through command-line, environment, or interactive interface).

When G<> appears within a block marked :masked, both the inline and surrounding content are concealed; the masking operation is idempotent.

Guard is a property of content, not of location. Content marked with G<> or carrying :masked renders concealed wherever it appears in rendered output. The rule applies when content is reached through links, inclusion, aliases, or data references.

The G<> code is not processed inside code blocks by default. To enable masking in code blocks, the :allow<G> attribute is required on the =code block (see :allow).

=begin code :lang<python> :allow<G>
api_key = "G<sk-12345>"
=end code

The G<> code marks content for concealment at render time but does not protect it. The original text remains in plain form in source files, document model, version control, and any consumer that does not invoke the renderer. For cryptographic security or access control, complementary mechanisms (file permissions, encryption, authenticated access) are required.

Links

The L<> code is used to specify all kinds of links, filenames, citations, and cross-references (both internal and external).

A link specification consists of a scheme specifier terminated by a colon, followed by an external address (in the scheme's preferred syntax), followed by an internal address (again, in the scheme's syntax). All three components are optional, though at least one must be present in any link specification.

Usually, in schemes where an internal address makes sense, it will be separated from the preceding external address by a #, unless the particular addressing scheme requires some other syntax. When new addressing schemes are created specifically for Podlite, it is strongly recommended that # be used to mark the start of internal addresses.

Standard schemes include:

http: and https:

A standard web URL. For example:

  This module needs the LAME library
  (available from L<http://www.mp3dev.org/mp3/>)

If the link does not start with // it is treated as being relative to the location of the current document:

  See also: L<http:tutorial/faq.html> and
  L<http:../examples/index.html>

file:

A filename on the local system. For example:

  Next, edit the global config file (that is, either
  L<file:/usr/local/lib/.configrc> or L<file:~/.configrc>).

Filenames that don't begin with a / or a ~ are relative to the current document's location:

    Then, edit the local config file (that is, either
    L<file:.configrc> or L<file:CONFIG/.configrc>.

mailto:

An email address. Typically, activating this type of link invokes a mailer. For example:

  Please forward bug reports to L<mailto:[email protected]>

man:

A link to the system manpages. For example:

  This module implements the standard
  Unix L<man:find(1)> facilities.

doc:

A link to other documents by utilizing semantic blocks such as =TITLE or =NAME as anchor points for these links.

For example:

  =NAME Dumper

  You may wish to use L<doc:Dumper> to
  view the results.

Moreover, the doc: scheme allows the use of an :id attribute within the =TITLE or =NAME blocks to create unique identifiers for document linking. This ensures precision in navigation, as each identifier corresponds to a specific part of the document set. An example would be:

    =for TITLE :id<Specification>
    The Specification of Podlite

    ...

    Read the L<spec|doc:Specification>.

    ...

When Podlite processes a link, it can automatically use the document's title from the =TITLE or =NAME blocks as the display text for the hyperlink if no explicit text is provided. For example:

   =for TITLE :id<Specification>
       The Specification of Podlite

   =para
   Please read "L<doc:Specification>".

... will be rendered as:

 Please read "The Specification of Podlite".

defn:

A link to the block-form or inline definition of the specified term within the current document. For example:

  He was highly prone to D<lexiphania>: an unfortunate proclivity
  for employing grandiloquisms (for example, words such as "proclivity",
  "grandiloquism", and indeed "lexiphania").

  =defn glossoligation
  Restraint of the tongue (voluntary or otherwise)

and later, to link back to the definition:

To treat his chronic L<defn:lexiphania> the doctor prescribed an
immediate L<defn:glossoligation> or, if that proved ineffective,
a complete cephalectomy.

isbn: and issn:

The International Standard Book Number or International Standard Serial Number for a publication. For example:

  The Perl Journal was a registered
  serial publication (L<issn:1087-903X>)

To refer to a specific section within a webpage, manpage, or Podlite document, add the name of that section after the main link, separated by a #. For example:

  Also see: L<man:bash(1)#Compound Commands>,
  L<doc:perlsyn#For Loops>, and
  L<http://dev.perl.org/perl6/syn/S04.html#The_for_statement>

To refer to a section of the current document, omit the external address:

  This mechanism is described under L<doc:#Special Features> below.

The scheme name may also be omitted in that case:

  This mechanism is described under L<#Special Features> below.

Podlite includes the possibility of assigning a unique identifier to a block. These identifiers can be explicitly assigned to any blocks using the :id attribute. Later, these identifiers are utilized for addressing blocks and creating links.

  =for head1 :id<intro>
  Introduction
  =for para :id<id1>
  This is an introductory paragraph.

  For more information, see L<here|#intro> and L<here|#id1>

In this example, the link reference to the header block identified by "intro" rather than the name "Introduction" and to the paragrapth block with identifier "id1".

Normally a link is presented as some rendered version of the link specification itself. However, you can specify an alternate presentation by prefixing the link with the desired text and a vertical bar. Whitespace is not significant on either side of the bar. For example:

  This module needs the L<LAME library|http://www.mp3dev.org/mp3/>.

  You could also write the code
  L<in Latin | doc:Lingua::Romana::Perligata>

  His L<lexiphanic|defn:lexiphania>> tendencies were, alas, incurable.

Contextual backlinks

Podlite introduces the concept of contextual backward links W<> (or contextual backlinks), enhancing the traditional linking mechanism by allowing to not only reference another location but also provide specific context around that reference. This context can take the form of opinions, additional information, or any relevant commentary that enhances the understanding of the referenced material.

For example:

  This text can reveal the meaning of W<glossoligation|defn:glossoligation>

or:

  We discuss here about W<doc:perldata>.

Contextual backlinks on the destination page can be displayed in various ways. They may appear with surrounding text chunks, providing context within the flow of the content. Alternatively, they can be placed at the end of the text, in the margin of the page, or highlighted in other visually distinctive ways.

Like traditional links, contextual backlinks allows the use of all available link schemes, including https: and doc:, to link to external content.

Contextual backlinks might be visually distinguished from standard links through color coding.

Link configuration attributes

The L<> and W<> markup codes may be extended with optional configuration attributes following the link specification. These attributes are specified using the standard Podlite configuration syntax.

The general form is:

  L<[text|]linkspec [:attr1 :attr2<value> ...]>
  W<[text|]linkspec [:attr1 :attr2<value> ...]>

The configuration portion begins at the first whitespace character that is immediately followed by a colon (:). The substring preceding this boundary constitutes the link specification. This boundary rule is unambiguous because URL schemes begin with a letter character, not a colon, and standard URLs do not contain space-colon sequences.

For example:

  L<https://example.com :new>

In this example, the boundary occurs at the space before :new.

The following attributes are defined:

For example:

  L<API Reference|https://api.example.com :new :title('Official documentation')>

  L<Download SDK|https://example.com/sdk.tar.gz :download<sdk-v2.tar.gz>>

  L<French Guide|https://example.fr/guide :lang<fr>>

  W<related term|defn:glossary :title('See definition')>

When the same attribute is specified both in =config L<> and in an inline L<> instance, the inline value takes precedence:

  =config L<> :new

  =comment inherits :new
  L<External|https://example.com>

  =comment overrides to false
  L<Internal|file:local.html :!new>

Link specifications containing literal spaces are required to be quoted. The file: scheme commonly requires this treatment:

  =comment correct
  L<file:'my document.txt' :download>

Colons within URLs (such as port numbers or path parameters) are not preceded by whitespace and therefore do not trigger attribute parsing:

  =comment  :8080 is port
  L<http://localhost:8080/api :new>

  =comment  :id is path
  L<https://api.example.com/users/:id :title('User profile')>

Parsers that do not implement this extension treat the entire content of L<> as a link specification. The link remains functional; only metadata is lost. Renderers that encounter unknown attributes are required to ignore them without error.

Alias placements

The A<> code is replaced by the contents of the named alias or object specified within its delimiters. For example:

  =alias PROGNAME    Earl Irradiatem Eventually
  =alias VENDOR      4D Kingdoms
  =alias TERMS_URL   L<http://www.4dk.com/eie>

  The use of A<PROGNAME> is subject to the terms and conditions
  laid out by A<VENDOR>, as specified at A<TERMS_URL>.

See #Aliases for further details of the aliasing macro mechanism.

Space-preserving text

Any text enclosed in an S<> code is formatted normally, except that every whitespace character in it—including any newline—is preserved. These characters are also treated as being non-breaking (except for the newlines, of course). For example:

The emergency signal is: S<
    dot dot dot   dash dash dash   dot dot dot>.

would be formatted like so:

The emergency signal is:… dot dot dot   dash dash dash    dot dot dot.

rather than:

The emergency signal is: dot dot dot dash dash dash dot dot dot.

Entities

To include Unicode code points or HTML5 character references in a Podlite document, specify the required entity using the code.

If the contains a number, that number is treated as the decimal Unicode value for the desired code point. For example:

Podlite makes considerable use of E<171> and E<187>.

You can also use explicit binary, octal, decimal, or hexadecimal numbers:

Podlite makes considerable use of E<0b10101011> and E<0b10111011>.
    Podlite makes considerable use of E<0o253> and E<0o273>.
    Podlite makes considerable use of E<0d171> and E<0d187>.
    Podlite makes considerable use of E<0xAB> and E<0xBB>.

If the contains anything that is not a number, the contents are interpreted as a Unicode character name (which is always uppercase), or else as an HTML5 named character reference. For example:

Podlite makes considerable use of E<LEFT DOUBLE ANGLE BRACKET>
    and E<RIGHT DOUBLE ANGLE BRACKET>.

or, equivalently:

Podlite makes considerable use of E<laquo> and E<raquo>.

To include emoji codes, you can use the code along with the colon-prefixed and postfix emoji shortname:

Podlite uses emoji codes to express emotions and actions,
    such as E<:thumbsup:> for approval and E<:smile:> for happiness.

In this example, :smile: and :thumbsup: are emoji codes representing the respective emojis. You can use any valid emoji code in this format to include emojis in your Podlite document.

Note that the specific emoji codes and the emojis they represent may vary depending on the platform or system you are using.

Multiple consecutive entities (in any format) can be specified in a single code, separated by semicolons:

Podlite makes considerable use of E<LEFT DOUBLE ANGLE BRACKET;hellip;0xBB;:smile:>.

Indexing terms

Anything enclosed in an X<> code is an index entry. The contents of the code are both formatted into the document and used as the (case-insensitive) index entry:

    An X<array> is an ordered list of scalars indexed by number,
    starting with 0. A X<hash> is an unordered collection of scalar
    values indexed by their associated string key.

An index entry where the indexed text and the index entry differ can be specified by separating the two with a vertical bar:

  An X<array|arrays> is an ordered list of scalars indexed by number,
  starting with 0. A X<hash|hashes> is an unordered collection of
  scalar values indexed by their associated string key.

In the two-part form, the index entry comes after the bar and is case-sensitive.

Hierarchical index entries can be specified by separating indexing levels with commas:

  An X<array|arrays, definition of> is an ordered list of scalars
  indexed by number, starting with 0. A X<hash|hashes, definition of>
  is an unordered collection of scalar values indexed by their
  associated string key.

Multiple entries for a single indexed text can be specified by separating the entries with semicolons:

  A X<hash|hashes, definition of; associative arrays>
  is an unordered collection of scalar values indexed by their
  associated string key.

Both notations describe one structure: a list of entries, each of which is a list of levels. The order of entries and the order of levels are significant. Whitespace adjacent to either separator is not part of a value.

The indexed text can be empty, creating a "zero-width" index entry:

  X<|puns, deliberate>This is called the "Orcish Manoeuvre"
  because you "OR" the "cache".

Annotations

Anything enclosed in an N<> code is an inline note. For example:

  Space stations feature hydroponic gardens N<Plants grow without soil,
  using mineral nutrient solutions.>, a necessity for long-term missions.

Renderers may present such annotations in various ways: as footnotes, endnotes, sidebars, pop-ups, tooltips, or expandable tags. They are never rendered as unmarked inline text. The previous example might be rendered as:

Space stations feature hydroponic gardens †, a necessity for long-term missions. and later:

Footnotes

† Plants grow without soil, using mineral nutrient solutions.

Module-defined handler for extends markup features

The M<> code in Podlite extends the language's capabilities by allowing users to specify additional processing instructions within their documents. This is achieved by combining content text with a custom plug-in specifier, followed by optional configuration information that is passed to a handler function.

The structure of the M<> markup code as follows:

M< CONTENT-TEXT| R<MODULE_NAME> R<OPTIONAL CONFIG INFO>>

This syntax includes CONTENT-TEXT section, followed by a name specifier MODULE_NAME and then the OPTIONAL CONFIG INFO (see "Configuration syntax options"). The name specifier should follow the same rules as for named blocks.

The M<> markup code is the inline equivalent of a named block.

An example of how this code might be used is :

    M< This text is highlighted in yellow |Marker :color('yellow') >.

In this example, the text "This text is highlighted in yellow" is subject to special handling specified by the Marker module and :color('yellow'), indicating that the text should be highlighted in yellow.

If the MODULE_NAME is unrecognized, the content text CONTENT-TEXT should be rendered as ordinary text. This ensures that documents remain readable even if specific processing instructions cannot be executed. The renderer could provide an unobtrusive yet informative error message, explaining that the custom markup block could not be processed.

Block pre-configuration

The =config directive allows you to prespecify standard configuration information that is applied to every block of a particular type.

  =config code     :lang<python> :allow<B>
  =config head1    :numbered
  =config head2    :folded


Here, two configurations are outlined. The first one sets the language for code blocks to python and allows bold markup. The second establishes that all level 1 headings will be numbered.

The general syntax for configuration directives is:

    =config BLOCK_TYPE  CONFIG OPTIONS
    =                   OPTIONAL EXTRA CONFIG OPTIONS

A =config is a directive, not a block. Hence, there is no paragraph or delimited form of the =config directive. Each =config specification is lexically scoped to the surrounding block or file in which it is specified.

Note that, if a particular block later explicitly specifies a configuration option with the same key, that option overrides the pre-configured option. For example, given the code blocks configurations in the previous example, to specify another language for code block:

  =for code :lang<javascript>
  print(JSON.stringify([1,2]]));

Pre-configuring markup codes

You can also lexically preconfigure a markup code, by naming it with a pair of angles as a suffix. For example:

  =comment  Always allow E<> codes in any (implicit or explicit) V<> code...
  =config V<>  :allow<E>
  =comment  All inline code allows I<>
  =config C<>  :allow<I>

Note that, even though the markup code is named using single-angles, the preconfiguration applies regardless of the actual delimiters used on subsequent instances of the code.

For per-block attribute assignment that targets a single block instance rather than setting type-wide defaults, see Block attribute assignment with =set.

Block attribute assignment with =set

The =set directive assigns attribute values to the next block in the same lexical scope. Like =config, it sets attributes for a block; unlike =config, it targets a single block instance rather than all blocks of a type. Attribute values may include multiline content with inline markup codes.

The directive has two syntax variants. Configuration syntax uses standard delimited attribute values, for example:

=set :caption('Product comparison') :id<table-1>
=set :lang<en> :numbered

=begin table
...
=end table

Alias syntax permits multiline values with inline markup codes, for example:

=set :caption Selected chemical elements with their
=             L<atomic numbers|#elements> and symbols

=begin table
Element     Symbol    Atomic Number
=========   ======    =============
Hydrogen    H         1
Carbon      C         6
Oxygen      O         8
=end table

Continuation lines (= followed by whitespace) extend multiline alias values until the next non-continuation directive or a blank line. Lines join into the final value before markup processing.

Both syntax variants may be mixed across continuation lines, as in the following example combining configuration-syntax continuation (= :folded<true>) with alias-syntax continuation:

=set :id<special-table>
=    :folded<true>
=set :caption Product Performance Metrics
=             with detailed analysis

=begin table
...
=end table

The table receives all three attributes (:id, :folded, :caption).

=set assignments override =config defaults but yield to explicit attributes on the block declaration. When multiple =set directives assign the same attribute key, the last assignment wins, regardless of syntax variant.

Directives (=set, =config, =alias, =include, =boundary) and =comment blocks are transparent to =set targeting and do not consume the assignment. For example:

=set :caption Renewable energy sources
=config table :width<100%>
=alias COMPANY Acme Corp
=comment Approved
=begin table
Source      Type
=========   ==========
Solar       photovoltaic
Wind        turbine
=end table

The =table block receives the :caption attribute despite the intervening directives and =comment.

For =include, attributes apply to the first block of the resolved included content. =set directives inside an included file are lexically scoped to that file and do not leak to the parent file.

If no block follows before the end of the containing block or file, parsers issue a warning that the =set directive has no target.

Aliases

The =alias directive provides a way to define lexically scoped synonyms for longer Podlite sequences, (meta)object declarators from the code, or even entire chunks of ambient source. These synonyms can then be inserted into subsequent Podlite using the A<> markup code.

Note that =alias is a fundamental Podlite directive, like =begin or =for; there are no equivalent paragraph or delimited forms.

Macro aliases are lexically scoped to the surrounding Podlite block.

The simplest form of alias takes two arguments. The first is an identifier (which is usually specified in uppercase, though this is certainly not mandatory). The second argument consists of one or more lines of replacement text.

This creates a lexically scoped Podlite macro that can be invoked during document generation by placing the identifier (i.e. the first argument of the alias) in an A<> markup code. This markup code is then replaced by the text returned by new macro.

The replacement text returned by the alias macro begins at the first non-whitespace character after the alias's identifier and continues to the end of the line. The replacement text can extend over multiple lines by starting each following line with an = (at the same level of indentation as the =alias directive itself) followed by at least one whitespace. Each additional line uses the original line's (virtual) left margin, as specified by the indentation of the replacement text on the =alias line.

For example:

    =alias PROGNAME    Earl Irradiatem Evermore
    =alias VENDOR      4D Kingdoms
    =alias TERMS_URLS  =item L<http://www.4dk.com/eie>
    =                  =item L<http://www.4dk.co.uk/eie.io/>
    =                  =item L<http://www.fordecay.ch/canttouchthis>

    The use of A<PROGNAME> is subject to the terms and conditions
    laid out by A<VENDOR>, as specified at:

        A<TERMS_URLS>

This would produce:

The use of Earl Irradiatem Evermore is subject to the terms and conditions laid out by 4D Kingdoms Inc, as specified at:

• http://www.4dk.com/eie

• http://www.4dk.co.uk/eie.io/

• http://www.fordecay.ch/canttouchthis

The advantage of using aliases is that the same alias can be reused in multiple places in the documentation. If the replacement text needs to be changed, it requires modification in only a single place:

    =alias PROGNAME    Count Krunchem Constantly
    =alias VENDOR      Last Chance Receivers Intl
    =alias TERMS_URLS  L<http://www.c11.com/generic_conditions>

Notification blocks

These blocks, often referred to as admonitions, callouts, or alerts, serve to draw attention to different types of content, such as tips, warnings, or important notes.

To create specially formatted blocks highlighting information in Podlite, the =nested block and :notice attribute are used.

For example:

    =begin nested :notify<tip>
    Remember to always use oven mitts when handling hot bakeware
    to prevent burns.
    =end nested

Below is a table outlining the different types of notification blocks along with a brief description of each type.

By default, the title of the notification block is its type identifier in title case. The title of the block and visibility of the information can be customized using the :caption and :folded options.

  =begin nested :caption("Astronaut's Reminder") :notify<important> :folded
    Space missions require meticulous planning and adherence to safety protocols.
    Neglecting these can lead to mission failure or, worse, endanger lives.
  =end nested

Title-only callouts can be created by omitting the body.

  =for nested :notify<important> :folded :caption("Title-only callout")

Notification blocks are displayed with distinctive colors and icons that indicate the significance of the content.
